909 Brass RPZ Hot Water

ENQUIRE NOW

SKU-909LF-20LFHW 20mm

SKU-909LF-25LFHW 25mm

DESCRIPTION SPECIFICATIONS DOWNLOADS VIDEO
  • High Hazard Device
  • Testable Device
  • Protects against back pressure & back Syphonage
  • Suitable for Vertical or Horizontal Installation
  • Must be installed above ground with a minimum of 300mm clearance to relief port
  • Continuous and non continuous pressure installation
  • Bronze
  • 0.5˚C to 60˚C continuous, 82˚C intermittent
  • 909HW 0.5˚C to 99˚C
  • Maximum pressure 1200kPa
  • 20mm - 50mm BSP threaded
title

909 Spec

291.00 kb
title

Discharge rates

966.00 kb
title

909 Spare Parts

143.00 kb
